Copley Controls R10-230-36-S Xenus R10 Ruggedized Servo Drive
- Brand
- Copley Controls
- Model
- R10-230-36-S
- GEARWELL SKU
- GWP-000024972
- Category
- Servo Systems
Key specifications
- Feedback
- Digital quad A/B encoder, analog Sin/Cos encoder, digital Halls
- Dimensions
- 192 x 142 x 65 mm
- Peak current
- 36 (25.5 Arms) Adc
- Code suffix "-S"
- as collected; R10-230-36-S is listed as a separate model in Copley's R10 MTBF report (P/N 00-00801-000); option content not defined in the datasheet
- Control power
- +20 to +32 VDC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Copley Controls R10-230-36-S Xenus R10 Ruggedized Servo Drive |
|---|---|
| Brand | Copley Controls |
| Model | R10-230-36-S |
| Category | Servo Systems |
| Feedback | Digital quad A/B encoder, analog Sin/Cos encoder, digital Halls |
| Dimensions | 192 x 142 x 65 mm |
| Peak current | 36 (25.5 Arms) Adc |
| Code suffix "-S" | as collected; R10-230-36-S is listed as a separate model in Copley's R10 MTBF report (P/N 00-00801-000); option content not defined in the datasheet |
| Control power | +20 to +32 VDC |
| Mains voltage | 100-240 VAC, 1-phase or 3-phase, 47-400 Hz |
| Communications | CANopen, RS-232 |
| Continuous current | 12 (8.5 Arms) Adc |
