CKD DVL-S-10-H1010-400 DVL Dial Needle Valve with Check Valve
- Brand
- CKD
- Model
- DVL-S-10-H1010-400
- GEARWELL SKU
- GWP-000021664
- Category
- Valves & Manifolds
Key specifications
- Tube O.D.
- ø10 (H1010) mm
- Body size
- 10 (3/8 thread equivalent)
- Working fluid
- Compressed air
- Control method
- S: check valve
- Proof pressure
- 1.5 MPa
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | CKD DVL-S-10-H1010-400 DVL Dial Needle Valve with Check Valve |
|---|---|
| Brand | CKD |
| Model | DVL-S-10-H1010-400 |
| Category | Valves & Manifolds |
| Tube O.D. | ø10 (H1010) mm |
| Body size | 10 (3/8 thread equivalent) |
| Working fluid | Compressed air |
| Control method | S: check valve |
| Proof pressure | 1.5 MPa |
| Fluid temperature | 5 to 60 °C |
| Max. working pressure | 1.0 MPa |
| Min. working pressure | 0.1 MPa |
| Needle control range | 1 to 13 rotations |
| Controlled flow rate (code 400) | 440 l/min (ANR) |
