CKD AB31-02-4-02E-DC24V AB31 Direct Acting 2-Port Solenoid Valve
- Brand
- CKD
- Model
- AB31-02-4-02E-DC24V
- GEARWELL SKU
- GWP-000023389
- Category
- Valves & Manifolds
Key specifications
- Weight
- 0.35 kg
- Function
- 2-port, NC (open when energized)
- Body/seal
- Copper alloy / nitrile rubber (standard)
- Port size
- Rc1/4 (code 02)
- Coil housing
- DIN terminal box G1/2 (code 2E)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | CKD AB31-02-4-02E-DC24V AB31 Direct Acting 2-Port Solenoid Valve |
|---|---|
| Brand | CKD |
| Model | AB31-02-4-02E-DC24V |
| Category | Valves & Manifolds |
| Weight | 0.35 kg |
| Function | 2-port, NC (open when energized) |
| Body/seal | Copper alloy / nitrile rubber (standard) |
| Port size | Rc1/4 (code 02) |
| Coil housing | DIN terminal box G1/2 (code 2E) |
| Orifice size | 3.5 (code 4) mm |
| Rated voltage | 24 V DC |
| Max. working pressure | 5 MPa |
| Power consumption (2E coil, DC) | 8.1 W |
| Max. working pressure differential (air, DC) | 0.4 MPa |
