CHINT NJBK7-800/5/AC220V 1A~5A NJBK7 Motor Protection Relay

Key specifications

Material number: 710220200000013
Type designation: NJBK7-800/5
Enclosure protection: IP20
Protection functions: Overload, blocking, phase loss, three-phase unbalance, undercurrent, grounding, PTC temperature, communication failure
Optional function code: none (no RS485, no 4-20 mA output)

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	CHINT NJBK7-800/5/AC220V 1A~5A NJBK7 Motor Protection Relay
Brand	CHINT
Model	NJBK7-800/5/AC220V 1A~5A
Category	Circuit Protection
Material number	710220200000013
Type designation	NJBK7-800/5
Enclosure protection	IP20
Protection functions	Overload, blocking, phase loss, three-phase unbalance, undercurrent, grounding, PTC temperature, communication failure
Optional function code	none (no RS485, no 4-20 mA output)
Rated insulation voltage	690 V AC
Rated current specification	1-5 A
Rated control supply voltage	AC 220 V
Rated impulse withstand voltage Uimp	4 kV
