Beijer E1101 E1000 Series 10.4" HMI Touch Panel
- Brand
- Beijer
- Model
- E1101
- GEARWELL SKU
- GWP-000023475
- Category
- HMIs & Industrial PCs
Key specifications
- Display
- 10.4" TFT, 64K colours
- Ethernet
- 10/100 Mbit/s shielded RJ45
- Backlight
- CCFL with dimming
- Operation
- Touch screen
- Resolution
- 800 x 600 px
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Beijer E1101 E1000 Series 10.4" HMI Touch Panel |
|---|---|
| Brand | Beijer |
| Model | E1101 |
| Category | HMIs & Industrial PCs |
| Display | 10.4" TFT, 64K colours |
| Ethernet | 10/100 Mbit/s shielded RJ45 |
| Backlight | CCFL with dimming |
| Operation | Touch screen |
| Resolution | 800 x 600 px |
| Serial ports | RS232 9-pin D-sub; RS485/RS422 25-pin D-sub |
| Cut-out W x H | 265 x 206 mm |
| Supply voltage | 24 (20-30) V DC |
| Dimensions W x H x D | 302 x 228 x 64 mm |
| Front/back protection | IP66/IP20 |
