BAUMER TE2-1.4.3020.0050.0 TE2 Compact Hygienic Temperature Sensor
- Brand
- BAUMER
- Model
- TE2-1.4.3020.0050.0
- GEARWELL SKU
- GWP-000020677
- Category
- Pressure, Flow & Temperature
Key specifications
- Code positions
- as collected; block .3020. not listed on baumer.com (sibling TE2-1.4.1020.0050.0 = 50 mm, 4 … 20 mA transmitter)
- Output options
- 4 … 20 mA 2-wire transmitter or 1 x Pt100 4-wire (specify on order)
- Type designation
- TE2-1.4.3020.0050.0
- Process temperature
- -50 … 125 °C
- Sensor tube material
- AISI 316L (1.4404)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | BAUMER TE2-1.4.3020.0050.0 TE2 Compact Hygienic Temperature Sensor |
|---|---|
| Brand | BAUMER |
| Model | TE2-1.4.3020.0050.0 |
| Category | Pressure, Flow & Temperature |
| Code positions | as collected; block .3020. not listed on baumer.com (sibling TE2-1.4.1020.0050.0 = 50 mm, 4 … 20 mA transmitter) |
| Output options | 4 … 20 mA 2-wire transmitter or 1 x Pt100 4-wire (specify on order) |
| Type designation | TE2-1.4.3020.0050.0 |
| Process temperature | -50 … 125 °C |
| Sensor tube material | AISI 316L (1.4404) |
| Thermal response time T90 | ≤ 8.5 s |
| Degree of protection (EN 60529) | IP 68 with M12-A 4-pin and appropriate cable |
| Pt100 accuracy class (EN 60751) | 1/1 B ± (0.3 + 0.005 × t) °C |
| Surface roughness wetted parts | Ra ≤ 0.8 µm |
