BAUMER AFI5-A812.4002.0100 CombiLyz AFI5 Conductivity Sensor
- Brand
- BAUMER
- Model
- AFI5-A812.4002.0100
- GEARWELL SKU
- GWP-000021795
- Category
- Pressure, Flow & Temperature
Key specifications
- Series
- CombiLyz AFI5 (conductivity sensor with separate electronics)
- Interface code '.###2'
- not the HART ('4') or IO-Link ('6') code on the official page
- Process pressure
- ≤ 25 bar
- Type designation
- AFI5-A812.4002.0100
- Code positions "812"
- as collected; not decoded on the opened official page
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | BAUMER AFI5-A812.4002.0100 CombiLyz AFI5 Conductivity Sensor |
|---|---|
| Brand | BAUMER |
| Model | AFI5-A812.4002.0100 |
| Category | Pressure, Flow & Temperature |
| Series | CombiLyz AFI5 (conductivity sensor with separate electronics) |
| Interface code '.###2' | not the HART ('4') or IO-Link ('6') code on the official page |
| Process pressure | ≤ 25 bar |
| Type designation | AFI5-A812.4002.0100 |
| Code positions "812" | as collected; not decoded on the opened official page |
| Process connection | G 1 A hygienic, PEEK wetted parts |
| Degree of protection | IP67 / IP69K |
| Sensor length (code '.#1##') | 37 mm (G 1 A hygienic, PEEK) |
| Conductivity measuring span | 500 µS/cm … 1000 mS/cm (14 selectable ranges) |
| Compensated temperature range | -20 … 150 °C |
| Electronics housing (code position 1 'A') | FlexHousing, wall mounting |
