BAUMER AFI4-6810.4006.1300 CombiLyz AFI4 Conductivity Sensor
- Brand
- BAUMER
- Model
- AFI4-6810.4006.1300
- GEARWELL SKU
- GWP-000021792
- Category
- Pressure, Flow & Temperature
Key specifications
- Output
- 2 x 4...20 mA, IO-Link; IO-Link version
- Display
- With display, with activated relays
- Housing
- Rear process connection
- Configuration
- No configuration
- Type designation
- AFI4-6810.4006.1300
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | BAUMER AFI4-6810.4006.1300 CombiLyz AFI4 Conductivity Sensor |
|---|---|
| Brand | BAUMER |
| Model | AFI4-6810.4006.1300 |
| Category | Pressure, Flow & Temperature |
| Output | 2 x 4...20 mA, IO-Link; IO-Link version |
| Display | With display, with activated relays |
| Housing | Rear process connection |
| Configuration | No configuration |
| Type designation | AFI4-6810.4006.1300 |
| Process connection | G 1 A hygienic, PEEK, length 60 mm (A04) |
| Approvals / calibration | Standard approvals; No calibration certificate |
| Electrical connection | 2 x M16x1.5 cable gland, Plastic |
| Conductivity measuring span | 500 µS/cm … 1000 mS/cm (14 selectable ranges) |
| Process temperature / pressure | -20 … 140 °C permanent; ≤ 25 bar |
