BAUMER 11047485 HXC20NIR Camera Link NIR Industrial Camera
- Brand
- BAUMER
- Model
- 11047485
- GEARWELL SKU
- GWP-000020548
- Category
- Machine Safety & Vision
Key specifications
- Sensor
- CMOSIS CMV2000, 2/3" global shutter CMOS
- Lens mount
- C-mount
- Pixel size
- 5.5 × 5.5 µm
- Resolution
- 2048 × 1088 px
- Pixel formats
- Mono8 / Mono10 / Mono12
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | BAUMER 11047485 HXC20NIR Camera Link NIR Industrial Camera |
|---|---|
| Brand | BAUMER |
| Model | 11047485 |
| Category | Machine Safety & Vision |
| Sensor | CMOSIS CMV2000, 2/3" global shutter CMOS |
| Lens mount | C-mount |
| Pixel size | 5.5 × 5.5 µm |
| Resolution | 2048 × 1088 px |
| Pixel formats | Mono8 / Mono10 / Mono12 |
| Article number | 11047485 |
| Data interface | Camera Link Full, 2 × SDR26 |
| Voltage supply | 9.6 … 30 VDC |
| Type designation | HXC20NIR |
| Frame rate max. (full frame) | 337 fps |
