BASO H19NA-4 H19 High Pressure Safety Pilot Gas Valve
- Brand
- BASO
- Model
- H19NA-4
- GEARWELL SKU
- GWP-000023482
- Category
- Valves & Manifolds
Key specifications
- Gas types
- Natural, LP, LP gas-air
- Valve body
- Aluminum
- Power unit (A)
- Standard
- Code suffix "-4"
- as collected; customer-specific requirements position of the BASO ordering matrix
- Pilot tapping
- 1/8-27 NPT
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | BASO H19NA-4 H19 High Pressure Safety Pilot Gas Valve |
|---|---|
| Brand | BASO |
| Model | H19NA-4 |
| Category | Valves & Manifolds |
| Gas types | Natural, LP, LP gas-air |
| Valve body | Aluminum |
| Power unit (A) | Standard |
| Code suffix "-4" | as collected; customer-specific requirements position of the BASO ordering matrix |
| Pilot tapping | 1/8-27 NPT |
| Construction (N) | 1/4 x 1/4 in. inlet/outlet, with flow interrupter |
| Ambient temperature | -40 to 66 °C |
| Rated inlet pressure | 25 (1.72 bar) psi |
| Capacity (natural gas @ 2.5 psi) | 600,000 Btu/hr (176 kW) |
