AUTONICS TZN4S-14R TZN Series Dual PID Temperature Controller
- Brand
- AUTONICS
- Model
- TZN4S-14R
- GEARWELL SKU
- GWP-000022073
- Category
- Pressure, Flow & Temperature
Key specifications
- Size
- DIN W48xH48mm (terminal type)
- Status
- Discontinued (per Autonics product page)
- Option output
- Event 1
- Power voltage
- 100-240VAC 50/60Hz
- Control method
- ON/OFF control, P, PI, PD, PIDF, PIDS control
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AUTONICS TZN4S-14R TZN Series Dual PID Temperature Controller |
|---|---|
| Brand | AUTONICS |
| Model | TZN4S-14R |
| Category | Pressure, Flow & Temperature |
| Size | DIN W48xH48mm (terminal type) |
| Status | Discontinued (per Autonics product page) |
| Option output | Event 1 |
| Power voltage | 100-240VAC 50/60Hz |
| Control method | ON/OFF control, P, PI, PD, PIDF, PIDS control |
| Control output | Relay(250VAC 3A) |
| Display method | 4-digit 7-segment LED |
| Sampling cycle | 500 ms |
| Display accuracy | F.S ± 0.3% or 3℃, select the higher one |
| Input specification | Thermocouple: K(CA), J(IC), E(CR), T(CC), R(PR), S(PR), N(NN), W(TT); RTD: DPt100Ω, JPt100Ω; Analog: 1-5VDC, 0-10VDC, DC4-20mA |
