AUTONICS TK4H-14CN TK Series High Performance PID Temp. Controller
- Brand
- AUTONICS
- Model
- TK4H-14CN
- GEARWELL SKU
- GWP-000021942
- Category
- Pressure, Flow & Temperature
Key specifications
- Option input
- CT, digital (DI-1/2)
- Option output
- Alarm 1
- Power voltage
- 100-240VAC 50/60Hz
- Control method
- ON/OFF, P, PI, PD, PID
- Display method
- 4-digit 7-segment LED
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AUTONICS TK4H-14CN TK Series High Performance PID Temp. Controller |
|---|---|
| Brand | AUTONICS |
| Model | TK4H-14CN |
| Category | Pressure, Flow & Temperature |
| Option input | CT, digital (DI-1/2) |
| Option output | Alarm 1 |
| Power voltage | 100-240VAC 50/60Hz |
| Control method | ON/OFF, P, PI, PD, PID |
| Display method | 4-digit 7-segment LED |
| Sampling cycle | 50 ms |
| Control output 1 | Current (DC0/4-20mA) or SSR drive (11VDC) [ON/OFF] |
| Control output 2 | None (standard control) |
| Input specification | Thermocouple K, J, E, T, B, R, S, N, C, G, L, U, Platinel II; RTD DPt100, DPt50, JPt100, Cu100, Cu50, Nickel 120Ω; analog 0-100mV, 0-5V, 1-5V, 0-10V, 0-20mA, 4-20mA |
| Protection structure | IP65 (front panel) |
