AUTONICS THD-WD2-T THD Temperature/Humidity Transducer
- Brand
- AUTONICS
- Model
- THD-WD2-T
- GEARWELL SKU
- GWP-000021940
- Category
- Pressure, Flow & Temperature
Key specifications
- Mounting type
- Wall mount type
- Power voltage
- 24VDC
- Display method
- 3-digit 7-segment LED
- Accuracy (humidity)
- Typ. ±2%RH (10 to 90%RH, at room temp.)
- Accuracy (temperature)
- ±1.0℃ (at room temperature)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AUTONICS THD-WD2-T THD Temperature/Humidity Transducer |
|---|---|
| Brand | AUTONICS |
| Model | THD-WD2-T |
| Category | Pressure, Flow & Temperature |
| Mounting type | Wall mount type |
| Power voltage | 24VDC |
| Display method | 3-digit 7-segment LED |
| Accuracy (humidity) | Typ. ±2%RH (10 to 90%RH, at room temp.) |
| Accuracy (temperature) | ±1.0℃ (at room temperature) |
| Protection structure | IP65 (except sensor part) |
| Length of sensor pole | 200 mm |
| Measured range (humidity) | 0.0 to 99.9 %RH |
| Measured range (temperature) | -19.9 to 60.0 ℃ |
| Output (temperature/humidity) | RS485 communication |
