AUTONICS TCN4H-22R TCN Series Dual Display PID Temperature Controller
- Brand
- AUTONICS
- Model
- TCN4H-22R
- GEARWELL SKU
- GWP-000021932
- Category
- Pressure, Flow & Temperature
Key specifications
- Weight
- Approx. 194g (approx. 124g)
- Option output
- Alarm 1/2
- Power voltage
- 24VAC 50/60Hz, 24-48VDC
- Control method
- ON/OFF, P, PI, PD, PID
- Control output
- Relay (250VAC 3A) or SSR drive (12VDC) [ON/OFF]
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AUTONICS TCN4H-22R TCN Series Dual Display PID Temperature Controller |
|---|---|
| Brand | AUTONICS |
| Model | TCN4H-22R |
| Category | Pressure, Flow & Temperature |
| Weight | Approx. 194g (approx. 124g) |
| Option output | Alarm 1/2 |
| Power voltage | 24VAC 50/60Hz, 24-48VDC |
| Control method | ON/OFF, P, PI, PD, PID |
| Control output | Relay (250VAC 3A) or SSR drive (12VDC) [ON/OFF] |
| Display method | 4-digit 7-segment LED (dual display) |
| Sampling cycle | 100 ms |
| Proportional band | 0.1 to 999.9℃/℉ |
| Input specification | Thermocouple K(CA), J(IC), T(CC), R(PR), S(PR), L(IC); RTD DPt100Ω, Cu50Ω |
