AUTONICS KN-2211W KN-2000W 1-Channel Digital Indicator
- Brand
- AUTONICS
- Model
- KN-2211W
- GEARWELL SKU
- GWP-000021893
- Category
- Pressure, Flow & Temperature
Key specifications
- Alarm output
- 2-point relay, 250 VAC 3 A 1c
- Analog input
- ±1.0000 V, ±50.00 mV, ±200.0 mV, 1.000-10.000 V; 4.00-20.00 mA, 0.00-20.00 mA
- Power supply
- 24 VDC
- Input type TC
- K, J, E, T, R, B, S, N, C (W5), L, U, PLII (12 types)
- Input type RTD
- JPt100, DPt100, DPt50, Cu50, Cu100 (5 types)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AUTONICS KN-2211W KN-2000W 1-Channel Digital Indicator |
|---|---|
| Brand | AUTONICS |
| Model | KN-2211W |
| Category | Pressure, Flow & Temperature |
| Alarm output | 2-point relay, 250 VAC 3 A 1c |
| Analog input | ±1.0000 V, ±50.00 mV, ±200.0 mV, 1.000-10.000 V; 4.00-20.00 mA, 0.00-20.00 mA |
| Power supply | 24 VDC |
| Input type TC | K, J, E, T, R, B, S, N, C (W5), L, U, PLII (12 types) |
| Input type RTD | JPt100, DPt100, DPt50, Cu50, Cu100 (5 types) |
| Display accuracy | ±0.2% F.S. ±1 digit (25 °C ±5 °C) |
| Weight (unit only) | approx. 200 g |
| Ambient temperature | -10 to 50 °C |
| Transmission output | isolated DC 4-20 mA (PV transmission), load max. 600 ohm |
