AUO G065VN01 V2 6.5" VGA TFT-LCD Display Module
- Brand
- AUO
- Model
- G065VN01 V2
- GEARWELL SKU
- GWP-000023752
- Category
- HMIs & Industrial PCs
Key specifications
- Resolution
- 640 x RGB x 480 (VGA)
- Active area
- 132.48 x 99.36 mm
- Display mode
- TN, normally white
- Physical size
- 153.0 x 118.0 x 10.9 mm
- Screen diagonal
- 6.5 inch
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AUO G065VN01 V2 6.5" VGA TFT-LCD Display Module |
|---|---|
| Brand | AUO |
| Model | G065VN01 V2 |
| Category | HMIs & Industrial PCs |
| Resolution | 640 x RGB x 480 (VGA) |
| Active area | 132.48 x 99.36 mm |
| Display mode | TN, normally white |
| Physical size | 153.0 x 118.0 x 10.9 mm |
| Screen diagonal | 6.5 inch |
| Input voltage VDD | 3.3 (typ.) V |
| Contrast ratio (typ.) | 600:1 |
| White luminance (typ.) | 800 cd/m2 |
| Electrical interface | 1 channel LVDS |
| Operating temperature | -30 to +80 (panel surface) C |
