Anderson-Negele ILM-4/L20/S01/V/I63/N/X/W/X ILM-4 Conductivity Sensor
- Brand
- Anderson-Negele
- Model
- ILM-4/L20/S01/V/I63/N/X/W/X
- GEARWELL SKU
- GWP-000022703
- Category
- Test & Measurement
Key specifications
- Enclosure
- W = stainless steel cap with sight glass
- Order code
- ILM-4/L20/S01/V/I63/N/X/W/X
- Configuration
- X = default factory settings
- Signal module
- I63 = IO-Link and 2x 4...20 mA conductivity/temperature selectable, external range switching
- Head orientation
- V = vertical
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Anderson-Negele ILM-4/L20/S01/V/I63/N/X/W/X ILM-4 Conductivity Sensor |
|---|---|
| Brand | Anderson-Negele |
| Model | ILM-4/L20/S01/V/I63/N/X/W/X |
| Category | Test & Measurement |
| Enclosure | W = stainless steel cap with sight glass |
| Order code | ILM-4/L20/S01/V/I63/N/X/W/X |
| Configuration | X = default factory settings |
| Signal module | I63 = IO-Link and 2x 4...20 mA conductivity/temperature selectable, external range switching |
| Head orientation | V = vertical |
| Interface/Display | X = without |
| Process connection | S01 = CLEANadapt G1" |
| Measuring principle | Inductive conductivity measurement, 0...1000 mS/cm |
| Electrical connection | N = 2x M12 connector, 4 pin output, 5 pin input/power supply |
| Submersion length of toroid | L20 = 20 mm |
