Anderson-Negele ILM-4/L20/S01/V/A42/P/S/W/X Conductivity Sensor
- Brand
- Anderson-Negele
- Model
- ILM-4/L20/S01/V/A42/P/S/W/X
- GEARWELL SKU
- GWP-000022837
- Category
- Pressure, Flow & Temperature
Key specifications
- Evidence
- archived official PDF (web.archive.org copy of anderson-negele.com ILM-4_50089_en_na.pdf)
- Output (A42)
- 1x 4...20 mA conductivity value only, display prepared
- Enclosure (W)
- Stainless steel cap with sight glass
- Head orientation (V)
- Vertical head orientation
- Interface/Display (S)
- Simple User Interface with small display
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Anderson-Negele ILM-4/L20/S01/V/A42/P/S/W/X Conductivity Sensor |
|---|---|
| Brand | Anderson-Negele |
| Model | ILM-4/L20/S01/V/A42/P/S/W/X |
| Category | Pressure, Flow & Temperature |
| Evidence | archived official PDF (web.archive.org copy of anderson-negele.com ILM-4_50089_en_na.pdf) |
| Output (A42) | 1x 4...20 mA conductivity value only, display prepared |
| Enclosure (W) | Stainless steel cap with sight glass |
| Head orientation (V) | Vertical head orientation |
| Interface/Display (S) | Simple User Interface with small display |
| Suffix verification | Archived official ILM-4 order code table (Anderson Instrument product information 50089, 2016): enclosure W = stainless steel cap with sight glass; final position X = standard parameter configuration (S = customer-specified). A42 output exists only in this older table (current doc 50088 uses I42/I62/I63) |
| Submersion length (L20) | 20 mm |
| Process connection (S01) | CLEANadapt G1" hygienic |
| Electrical connection (P) | Cable gland M16x1.5 |
| Parameter configuration (X) | Standard |
