Allen-Bradley VPC-B3004A-MJ72FS Kinetix VP Continuous Duty Servo Motor
- Brand
- Allen-Bradley
- Model
- VPC-B3004A-MJ72FS
- GEARWELL SKU
- GWP-000003291
- Category
- PLCs & I/O
Key specifications
- Size
- 4 magnet stacks
- Current
- 400 V AC
- Product type
- Kinetix VP Continuous Duty Servo Motor
- Lifecycle status
- Active
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The Allen-Bradley VPC-B3004A-MJ72FS is a Kinetix VPC continuous-duty servo motor for the 400V class with an IEC 300 mm frame (shaft height 132 mm) and 4 magnet stacks, rated 30.0 kW at 1500 rpm with a cooling fan. Continuous stall torque is 191.1 N·m and peak stall torque 319.0 N·m; weight is about 116.7 kg. It has a 1024 sin/cos absolute multi-turn encoder (Hiperface), a shaft key, a right-angle SpeedTec DIN connector that rotates 180°, no brake, forced ventilation and a standard shaft seal. VPC motors are optimized for Kinetix 5700 drives.
Technical reference
| Product name | Allen-Bradley VPC-B3004A-MJ72FS Kinetix VP Continuous Duty Servo Motor |
|---|---|
| Brand | Allen-Bradley |
| Model | VPC-B3004A-MJ72FS |
| Category | PLCs & I/O |
| Size | 4 magnet stacks |
| Current | 400 V AC |
| Product type | Kinetix VP Continuous Duty Servo Motor |
| Lifecycle status | Active |
