Allen-Bradley 2711P-T4W22D8S PanelView Plus 7 Standard 4.3-inch Widescreen Touchscreen HMI
- Brand
- Allen-Bradley
- Model
- 2711PT4W22D8S
- GEARWELL SKU
- GWP-000000088
- Category
- HMIs & Industrial PCs
Key specifications
- Memory
- 512 MB RAM; 512 MB nonvolatile storage with approximately 80 MB available for applications
- Display size
- 4.3 in widescreen
- Product type
- PanelView Plus 7 Standard touchscreen terminal
- Input voltage
- 24 V DC nominal (18...30 V DC)
- Manufacturer catalog number
- 2711P-T4W22D8S
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The Allen-Bradley 2711P-T4W22D8S is a PanelView Plus 7 Standard operator terminal with a 4.3-in. widescreen color TFT touch screen at 480 x 272 WQVGA resolution, two 10/100 Ethernet ports for star, linear or DLR networks and a 24V DC supply. Rockwell sizes the Standard terminal for one controller, up to 100 screens and up to 500 alarms, and it runs FactoryTalk View Machine Edition applications on Windows CE with a PDF viewer, an SD card slot and USB host and device ports. It connects to ControlLogix 5570 and CompactLogix 5370 controllers over EtherNet/IP and is certified for Class I, Div. 2 and ATEX, IECEx and INMETRO Zones 2 and 22. Series D terminals need firmware version 13.x or later.
Technical reference
| Product name | Allen-Bradley 2711P-T4W22D8S PanelView Plus 7 Standard 4.3-inch Widescreen Touchscreen HMI |
|---|---|
| Brand | Allen-Bradley |
| Model | 2711PT4W22D8S |
| Category | HMIs & Industrial PCs |
| Memory | 512 MB RAM; 512 MB nonvolatile storage with approximately 80 MB available for applications |
| Display size | 4.3 in widescreen |
| Product type | PanelView Plus 7 Standard touchscreen terminal |
| Input voltage | 24 V DC nominal (18...30 V DC) |
| Manufacturer catalog number | 2711P-T4W22D8S |
| Ethernet interfaces | Two 10/100Base-T Ethernet ports; star, linear and DLR topologies |
| Manufacturer lifecycle status | Active |
| Display resolution | 480 x 272 WQVGA |
| Terminal configuration | 4.3-inch widescreen color touchscreen; dual-port DLR Ethernet; 24 V DC; Windows CE 6.0 |
