Allen-Bradley 2098-DSD-HV150-SE Ultra3000 SERCOS Servo Drive
- Brand
- Allen-Bradley
- Model
- 2098-DSD-HV150-SE
- GEARWELL SKU
- GWP-000001402
- Category
- Servo Systems
Key specifications
- Power
- 15 kW
- Current
- 34 A / 68 A
- Interface
- SERCOS
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The Allen-Bradley 2098-DSD-HV150-SE is an Ultra3000-SE servo drive with SERCOS interface from Rockwell's Ultra3000 digital servo drive family. It accepts 230…480V rms three-phase input and delivers 34 A continuous and 68 A intermittent output current (0-pk), with 15 kW continuous power output at 460V AC input. It connects to a ControlLogix 1756-MxxSE module or SoftLogix 1784-PM16SE card through the SERCOS fiber-optic interface. Operating ambient temperature is 0…55 °C and it weighs 10.44 kg.
Technical reference
| Product name | Allen-Bradley 2098-DSD-HV150-SE Ultra3000 SERCOS Servo Drive |
|---|---|
| Brand | Allen-Bradley |
| Model | 2098-DSD-HV150-SE |
| Category | Servo Systems |
| Power | 15 kW |
| Current | 34 A / 68 A |
| Interface | SERCOS |
