ABB SB822 ABB AC 800M controller / S800 I/O Rechargeable battery unit
- Brand
- ABB
- Model
- SB822
- GEARWELL SKU
- GWP-000014431
- Category
- Power Supplies
Key specifications
- Battery
- Lithium-ion 4.6 Ah / 17.0 Wh
- Connector
- 24 V DC
- Included cable
- TK821V020
- Type designation
- SB822
- Product net width
- 76.5 mm
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The ABB SB822 is a rechargeable external battery unit for extended memory back-up of the AC 800M controller. It is DIN-rail mounted, comes with a 2 m TK821V020 connecting cable and uses a rechargeable lithium-ion battery of 3.75V 2.3 Ah. It measures W 85.6 x D 51 x H 136 mm, weighs 600 g as a package and is rated IP20; the internal battery of the processor unit is removed when the external battery is used.
Technical reference
| Product name | ABB SB822 ABB AC 800M controller / S800 I/O Rechargeable battery unit |
|---|---|
| Brand | ABB |
| Model | SB822 |
| Category | Power Supplies |
| Battery | Lithium-ion 4.6 Ah / 17.0 Wh |
| Connector | 24 V DC |
| Included cable | TK821V020 |
| Type designation | SB822 |
| Product net width | 76.5 mm |
| Product net height | 139.5 mm |
| Product net weight | 0.55 kg |
| Product net depth/length | 184.5 mm |
