ABB S203-C10 System pro M compact S200 Miniature circuit breaker
- Brand
- ABB
- Model
- S203-C10
- GEARWELL SKU
- GWP-000014132
- Category
- Circuit Protection
Key specifications
- Weight
- 0.375 kg
- Rated current
- 10 A
- EAN (Bbn 4016779)
- 467803
- Number of poles
- 3
- Tripping characteristic
- C
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The ABB S203-C10 is a 3-pole System pro M compact S200 miniature circuit breaker with C tripping characteristic and 10 A rated current, ABB order code 2CDS253001R0104. It has a rated short-circuit capacity Icn of 6 kA to IEC/EN 60898-1 and is also listed to IEC/EN 60947-2. ABB specifies the C characteristic for protecting circuits against overload and short circuit with resistive and inductive loads with low inrush current, in residential, commercial and industrial installations. The S200 range has a red/green contact position indicator and finger-proof (IP20) twin terminals for cables up to 35 mm².
Technical reference
| Product name | ABB S203-C10 System pro M compact S200 Miniature circuit breaker |
|---|---|
| Brand | ABB |
| Model | S203-C10 |
| Category | Circuit Protection |
| Weight | 0.375 kg |
| Rated current | 10 A |
| EAN (Bbn 4016779) | 467803 |
| Number of poles | 3 |
| Tripping characteristic | C |
| Rated short-circuit capacity Icn | 6 kA |
