ABB PM865K01 Processor unit HI (controller CPU kit)
- Brand
- ABB
- Model
- PM865K01
- GEARWELL SKU
- GWP-000014440
- Category
- PLCs & I/O
Key specifications
- Memory
- 32 MB SDRAM, 4 MB flash PROM
- Power supply
- 24 V DC (19.2-30 V DC)
- Package weight
- 1200 g
- Power dissipation
- 6.9 typical W
- Protection rating
- IP20
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The ABB PM865K01 is a processor unit for the AC 800M High Integrity controller: one PM865 CPU (article 3BSE031151R1) with the required optional items. The CPU has an MPC862P processor at 96 MHz and 32 MB RAM, carries IEC 61508 SIL3 TÜV approval, supports CPU redundancy (switch-over max 10 ms) and executes 1000 boolean operations in 0.17 ms. Power consumption is 287/487 mA typical/max at +24 V. It runs on 24 V DC (19.2-30 V DC), is rated IP20 and +5 to +55 °C operating, and has two Ethernet channels for the control network.
Technical reference
| Product name | ABB PM865K01 Processor unit HI (controller CPU kit) |
|---|---|
| Brand | ABB |
| Model | PM865K01 |
| Category | PLCs & I/O |
| Memory | 32 MB SDRAM, 4 MB flash PROM |
| Power supply | 24 V DC (19.2-30 V DC) |
| Package weight | 1200 g |
| Power dissipation | 6.9 typical W |
| Protection rating | IP20 |
| Current consumption | 287 typical (487 max) mA |
| Dimensions (W x H x D) | 119 x 186 x 135 mm |
