ABB 3BSE007913R50 Pressductor PillowBlock load cells PFTL 201 Pillow block load cell, horizontal measuring, 50.0 kN
- Brand
- ABB
- Model
- 3BSE007913R50
- GEARWELL SKU
- GWP-000028826
- Category
- Test & Measurement
Key specifications
- Material
- Stainless steel SIS 2387 / DIN X4CrNiMo165
- Accuracy class
- 0.5 %
- Spring constant
- 1000 kN/mm
- Working temperature range
- -10 ... +90 °C
- Deflection at nominal load
- 0.050 mm
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | ABB 3BSE007913R50 Pressductor PillowBlock load cells PFTL 201 Pillow block load cell, horizontal measuring, 50.0 kN |
|---|---|
| Brand | ABB |
| Model | 3BSE007913R50 |
| Category | Test & Measurement |
| Material | Stainless steel SIS 2387 / DIN X4CrNiMo165 |
| Accuracy class | 0.5 % |
| Spring constant | 1000 kN/mm |
| Working temperature range | -10 ... +90 °C |
| Deflection at nominal load | 0.050 mm |
| Nominal load in measuring direction | 50.0 kN |
| Extended load in measuring direction | 75.0 kN |
| Overload capacity, measurement direction | 500.0 kN |
