ZIMMER GPP5006NC-00-A GPP5000 Pneumatic 2-Jaw Parallel Gripper
- Brand
- ZIMMER
- Model
- GPP5006NC-00-A
- GEARWELL SKU
- GWP-000021669
- Category
- Cylinders & Actuators
Key specifications
- Weight
- 0.35 kg
- Stroke per jaw
- 6 mm
- Operating pressure
- 4 ... 7 (nominal 6) bar
- Repetition accuracy
- +/- 0.01 mm
- Closing / opening time
- 0.015 / 0.035 s
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | ZIMMER GPP5006NC-00-A GPP5000 Pneumatic 2-Jaw Parallel Gripper |
|---|---|
| Brand | ZIMMER |
| Model | GPP5006NC-00-A |
| Category | Cylinders & Actuators |
| Weight | 0.35 kg |
| Stroke per jaw | 6 mm |
| Operating pressure | 4 ... 7 (nominal 6) bar |
| Repetition accuracy | +/- 0.01 mm |
| Closing / opening time | 0.015 / 0.035 s |
| Operating temperature | -10 ... +90 掳C |
| Protection to IEC 60529 | IP64 |
| Max. finger length / weight | 90 mm / 0.4 kg |
| Nominal gripping force (closing) | 455 N |
| Gripping force secured by spring, min. | 125 N |
