YOKOGAWA UR1800 Recorder

Key specifications

Display: 5 x 7 dot matrix VFD
Alarm types: High and/or low limit, difference high/low limit, rate-of-change limit
Input types: DC voltage ±20 mV to ±20 V; thermocouple R, S, B, K, J, T, N, W, L, U, PR20-40, Platinel; RTD Pt100/JPt100, Pt150, Cu10, Cu25; digital input (contact or DC voltage, TTL level); DC current (with external shunt resistor)
Chart length: 20 m
Number of inputs: 6, 12, 18 or 24 points

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	YOKOGAWA UR1800 Recorder
Brand	YOKOGAWA
Model	UR1800
Category	Test & Measurement
Display	5 x 7 dot matrix VFD
Alarm types	High and/or low limit, difference high/low limit, rate-of-change limit
Input types	DC voltage ±20 mV to ±20 V; thermocouple R, S, B, K, J, T, N, W, L, U, PR20-40, Platinel; RTD Pt100/JPt100, Pt150, Cu10, Cu25; digital input (contact or DC voltage, TTL level); DC current (with external shunt resistor)
Chart length	20 m
Number of inputs	6, 12, 18 or 24 points
Specification note	Specifications from supplier data; please verify against the nameplate before ordering.
Effective recording width	180 mm
Recording period (dot printing)	6 points/10 s, 12 points/15 s, 18 points/20 s, 24 points/30 s (fastest)
