XINJE TS2-400-E TouchWin TS2 series HMI Touch Panel
- Brand
- XINJE
- Model
- TS2-400-E
- GEARWELL SKU
- GWP-000024022
- Category
- HMIs & Industrial PCs
Key specifications
- Display
- 4.3 in TFT LCD, LED backlight, 16.77 million colours
- Software
- TouchWin Pro
- Processor
- Cortex-A7, 1 GHz
- Protection
- Front panel IP65
- Resolution
- 480 x 272 px
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | XINJE TS2-400-E TouchWin TS2 series HMI Touch Panel |
|---|---|
| Brand | XINJE |
| Model | TS2-400-E |
| Category | HMIs & Industrial PCs |
| Display | 4.3 in TFT LCD, LED backlight, 16.77 million colours |
| Software | TouchWin Pro |
| Processor | Cortex-A7, 1 GHz |
| Protection | Front panel IP65 |
| Resolution | 480 x 272 px |
| Touch panel | Four-wire resistive |
| Input voltage | 24 V DC (22-26 V DC) |
| Panel cut-out | 119.8 x 93.8 mm |
| External dimensions | 130.3 x 104.3 x 30.5 mm |
| Operating temperature | 0-50 °C |
