XINJE TGA63-MT TG Series HMI Touch Screen
- Brand
- XINJE
- Model
- TGA63-MT
- GEARWELL SKU
- GWP-000023917
- Category
- HMIs & Industrial PCs
Key specifications
- Memory
- 128 MB
- Display
- TFT LCD, 16.7M colours
- Dimensions
- 272.2 x 191.7 x 51.2 mm
- Resolution
- 1024 x 600 px
- Display size
- 10.1 in
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | XINJE TGA63-MT TG Series HMI Touch Screen |
|---|---|
| Brand | XINJE |
| Model | TGA63-MT |
| Category | HMIs & Industrial PCs |
| Memory | 128 MB |
| Display | TFT LCD, 16.7M colours |
| Dimensions | 272.2 x 191.7 x 51.2 mm |
| Resolution | 1024 x 600 px |
| Display size | 10.1 in |
| Panel cutout | 260.2 x 179.7 mm |
| Power supply | 22–26 VDC |
| Product type | HMI touch screen (human machine interface) |
| Communication ports | USB-B, COM1 RS232/485, COM2 RS232/485/422 |
| Current consumption | 270 mA |
