XINJE TG765-ET-C TG Series HMI Touch Screen
- Brand
- XINJE
- Model
- TG765-ET-C
- GEARWELL SKU
- GWP-000023893
- Category
- HMIs & Industrial PCs
Key specifications
- Memory
- 128 MB
- PLC port
- RS232/RS422/RS485
- Interfaces
- USB-A (U disk), USB-B, RJ45 Ethernet
- Resolution
- 800 x 480 px
- Touch panel
- 4-wire resistive
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | XINJE TG765-ET-C TG Series HMI Touch Screen |
|---|---|
| Brand | XINJE |
| Model | TG765-ET-C |
| Category | HMIs & Industrial PCs |
| Memory | 128 MB |
| PLC port | RS232/RS422/RS485 |
| Interfaces | USB-A (U disk), USB-B, RJ45 Ethernet |
| Resolution | 800 x 480 px |
| Touch panel | 4-wire resistive |
| Display size | 7 in |
| Panel cutout | 192.0 x 138.5 mm |
| Power supply | 24 VDC (22–26 VDC) |
| Product type | HMI touch screen (human machine interface) |
| Code suffix "C" | as collected; not listed in the official model-number table for TG765-ET (Xinje uses "-C" only on TG765-XT-C, with clock) |
