WOODWARD easYgen-3500XT Genset Controller
- Brand
- WOODWARD
- Model
- easYgen-3500XT
- GEARWELL SKU
- GWP-000032773
- Category
- PLCs & I/O
Key specifications
- Display
- 5.7 in color TFT LCD
- Mounting
- Panel, 144 x 144 mm
- Paralleling
- Up to 32 units
- Load sharing
- Active (kW) and reactive (kvar)
- Open options
- Package: -P1, -P2 or -LT (separate 8440- part numbers) per Woodward PS 37583 Rev E
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | WOODWARD easYgen-3500XT Genset Controller |
|---|---|
| Brand | WOODWARD |
| Model | easYgen-3500XT |
| Category | PLCs & I/O |
| Display | 5.7 in color TFT LCD |
| Mounting | Panel, 144 x 144 mm |
| Paralleling | Up to 32 units |
| Load sharing | Active (kW) and reactive (kvar) |
| Open options | Package: -P1, -P2 or -LT (separate 8440- part numbers) per Woodward PS 37583 Rev E |
| Communication | CANbus (J1939), Modbus RTU/TCP, 10/100 Mbit Ethernet |
| Supply voltage | 8-36 V DC |
| Protection class | IP65 front, IP20 body |
| Application modes | Standby, prime, parallel, hot standby |
| Power consumption | < 15 W |
| Specification note | Specifications from supplier data; please verify against the nameplate before ordering. |
| Storage temperature | -40 to +85 °C |
| Protection functions | Over/under voltage, over/under frequency, reverse power, reverse current, overspeed |
| Operating temperature | -25 to +70 °C |
