WOODWARD 9907-028 SPM-A Synchronizer (Non-Voltage Matching)
- Brand
- WOODWARD
- Model
- 9907-028
- GEARWELL SKU
- GWP-000026344
- Category
- PLCs & I/O
Key specifications
- Weight
- 2 kg (5 lb)
- Frequency
- 50/60 Hz
- Operating modes
- Run, Check, Permissive, Off
- Voltage matching
- No
- Power consumption
- 5 W maximum, from generator input
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | WOODWARD 9907-028 SPM-A Synchronizer (Non-Voltage Matching) |
|---|---|
| Brand | WOODWARD |
| Model | 9907-028 |
| Category | PLCs & I/O |
| Weight | 2 kg (5 lb) |
| Frequency | 50/60 Hz |
| Operating modes | Run, Check, Permissive, Off |
| Voltage matching | No |
| Power consumption | 5 W maximum, from generator input |
| Phase match window | ±10° |
| Ambient temperature | -54 to +66 °C |
| Catalog description | SPM-A STD NON VOLTAGE MATCH |
| Breaker close relay (resistive) | 10 A at 28 Vdc; 3 A at 115 Vac; 1.5 A at 230 Vac |
| Bus and generator voltage input | 115 or 230 Vac rms, 50/60 Hz |
