WOODWARD 8200-1302 505 Steam Turbine Control LVDC ATEX
- Brand
- WOODWARD
- Model
- 8200-1302
- GEARWELL SKU
- GWP-000026021
- Category
- PLCs & I/O
Key specifications
- Speed inputs
- 2 passive MPUs or 2 active proximity probes (0.5-35 000 Hz)
- Analog inputs
- 8 configurable 4-20 mA
- Input voltage
- LV 18-36 VDC isolated
- Relay outputs
- 8, rated 24 Vdc @ 5 A
- Communications
- 4 Ethernet (Modbus TCP/OPC), 1 serial Modbus
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | WOODWARD 8200-1302 505 Steam Turbine Control LVDC ATEX |
|---|---|
| Brand | WOODWARD |
| Model | 8200-1302 |
| Category | PLCs & I/O |
| Speed inputs | 2 passive MPUs or 2 active proximity probes (0.5-35 000 Hz) |
| Analog inputs | 8 configurable 4-20 mA |
| Input voltage | LV 18-36 VDC isolated |
| Relay outputs | 8, rated 24 Vdc @ 5 A |
| Communications | 4 Ethernet (Modbus TCP/OPC), 1 serial Modbus |
| Discrete inputs | 20 configurable contact inputs |
| Actuator outputs | 2, 4-20 mA or 20-200 mA |
| Operating temperature | -30 to +70 °C |
| Version (Woodward catalog) | 505 - LVDC, ATEX, Zone 2 Hazardous Location |
