WOODWARD 8200-1301 505 Steam Turbine Control HVAC/DC
- Brand
- WOODWARD
- Model
- 8200-1301
- GEARWELL SKU
- GWP-000026463
- Category
- PLCs & I/O
Key specifications
- Speed inputs
- 2 passive MPUs or 2 active proximity probes (0.5-35 000 Hz)
- Analog inputs
- 8 configurable 4-20 mA
- Relay outputs
- 8, rated 24 Vdc @ 5 A
- Analog outputs
- 6 x 4-20 mA
- Communications
- 4 Ethernet (Modbus TCP/OPC), 1 serial Modbus
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | WOODWARD 8200-1301 505 Steam Turbine Control HVAC/DC |
|---|---|
| Brand | WOODWARD |
| Model | 8200-1301 |
| Category | PLCs & I/O |
| Speed inputs | 2 passive MPUs or 2 active proximity probes (0.5-35 000 Hz) |
| Analog inputs | 8 configurable 4-20 mA |
| Relay outputs | 8, rated 24 Vdc @ 5 A |
| Analog outputs | 6 x 4-20 mA |
| Communications | 4 Ethernet (Modbus TCP/OPC), 1 serial Modbus |
| Discrete inputs | 20 configurable contact inputs |
| Actuator outputs | 2, 4-20 mA or 20-200 mA |
| Operating temperature | -30 to +70 °C |
| Power supply (HV models) | 88-264 Vac / 90-150 Vdc |
| Version (Woodward catalog) | 505 - HVAC/DC, Ordinary Location |
