WITTELB WIN-IO-4AOMC/MV-M WIN-IO 4-Ch Analog Output Module RS485
- Brand
- WITTELB
- Model
- WIN-IO-4AOMC/MV-M
- GEARWELL SKU
- GWP-000024148
- Category
- PLCs & I/O
Key specifications
- Enclosure
- DIN rail, 110 x 70 x 50 mm
- Addressing
- DIP switch 1-15 (soft 1-254 optional), baud 9600-115200
- Resolution
- 10 bit default (12 bit on request)
- Communication
- Modbus RTU RS485
- Analog outputs
- 4 (4-20 mA)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | WITTELB WIN-IO-4AOMC/MV-M WIN-IO 4-Ch Analog Output Module RS485 |
|---|---|
| Brand | WITTELB |
| Model | WIN-IO-4AOMC/MV-M |
| Category | PLCs & I/O |
| Enclosure | DIN rail, 110 x 70 x 50 mm |
| Addressing | DIP switch 1-15 (soft 1-254 optional), baud 9600-115200 |
| Resolution | 10 bit default (12 bit on request) |
| Communication | Modbus RTU RS485 |
| Analog outputs | 4 (4-20 mA) |
| SKU (base model) | IO-1010 |
| Supply voltage | 24 V AC/DC |
| Code suffix "/MV-M" | as collected; not listed in the official WittelB catalogue (only WIN-IO-4AOMC and WIN-IO-4AOMV) |
