WENGLOR Y1TA100MHV80 Laser Distance Sensor, Time-of-Flight
- Brand
- WENGLOR
- Model
- Y1TA100MHV80
- GEARWELL SKU
- GWP-000021644
- Category
- Proximity & Photoelectric Sensors
Key specifications
- Connection
- M12 x 1, 8-pin
- Resolution
- 1 ... 12 mm
- Light source
- Laser, red, 660 nm, laser class 2
- Analog output
- 0...10 V / 4...20 mA
- Working range
- 0.1 ... 10.1 m
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | WENGLOR Y1TA100MHV80 Laser Distance Sensor, Time-of-Flight |
|---|---|
| Brand | WENGLOR |
| Model | Y1TA100MHV80 |
| Category | Proximity & Photoelectric Sensors |
| Connection | M12 x 1, 8-pin |
| Resolution | 1 ... 12 mm |
| Light source | Laser, red, 660 nm, laser class 2 |
| Analog output | 0...10 V / 4...20 mA |
| Working range | 0.1 ... 10.1 m |
| Measuring rate | 1 ... 100 /s |
| Supply voltage | 18 ... 30 V DC |
| Switching outputs | 2 (PNP NO) |
| Temperature range | -25 ... 60 °C |
| Degree of protection | IP68 |
