WENGLOR OY2P303A0135 Laser Distance Sensor, Time-of-Flight
- Brand
- WENGLOR
- Model
- OY2P303A0135
- GEARWELL SKU
- GWP-000021640
- Category
- Proximity & Photoelectric Sensors
Key specifications
- Connection
- M12 x 1, 5-pin
- Light source
- Laser, red, 660 nm, laser class 1
- Response time
- 0.5 ms
- Setting range
- 200 ... 3,000 mm
- Working range
- 0 ... 3,000 mm
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | WENGLOR OY2P303A0135 Laser Distance Sensor, Time-of-Flight |
|---|---|
| Brand | WENGLOR |
| Model | OY2P303A0135 |
| Category | Proximity & Photoelectric Sensors |
| Connection | M12 x 1, 5-pin |
| Light source | Laser, red, 660 nm, laser class 1 |
| Response time | 0.5 ms |
| Setting range | 200 ... 3,000 mm |
| Working range | 0 ... 3,000 mm |
| Supply voltage | 10 ... 30 V DC |
| Switching outputs | 2 x PNP (NO / NC) |
| Temperature range | -40 ... 60 °C |
| Switching frequency | 1,000 Hz |
| Degree of protection | IP68 |
