WENGLOR CP24MHT80 Laser Distance Sensor, Triangulation
- Brand
- WENGLOR
- Model
- CP24MHT80
- GEARWELL SKU
- GWP-000021633
- Category
- Proximity & Photoelectric Sensors
Key specifications
- Interface
- RS-232
- Connection
- M12 x 1, 8-pin
- Light source
- Laser, red, 660 nm, laser class 2
- Analog output
- 0...10 V / 4...20 mA (configurable)
- Response time
- 660 µs
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | WENGLOR CP24MHT80 Laser Distance Sensor, Triangulation |
|---|---|
| Brand | WENGLOR |
| Model | CP24MHT80 |
| Category | Proximity & Photoelectric Sensors |
| Interface | RS-232 |
| Connection | M12 x 1, 8-pin |
| Light source | Laser, red, 660 nm, laser class 2 |
| Analog output | 0...10 V / 4...20 mA (configurable) |
| Response time | 660 µs |
| Working range | 40 ... 160 mm |
| Supply voltage | 18 ... 30 V DC |
| Measuring range | 120 mm |
| Linearity deviation | 350 µm |
| Degree of protection | IP67 |
