Weintek CMT2159X HMI Touch Panel

Product overview

The Weintek cMT2159X is a 15-inch cMT X series operator panel with a 1024 x 768 VA LCD (LED backlight, 350 cd/m2, 2500:1 contrast) and a 4-wire resistive touch screen. It runs on a quad-core RISC processor with 4 GB flash, 1 GB RAM, a built-in RTC and an SD/SDHC slot, in a fanless aluminum housing with a coated PCB. Ports are LAN 1 10/100/1000 Base-T, LAN 2 10/100 Base-T, one USB 2.0 host, COM1 and COM3 as RS-485 or RS-232 on two D-sub connectors, a built-in mono speaker and a 3.5 mm audio line out. Power is 24±20%VDC with built-in isolation (1.3A at 24VDC), the front panel is NEMA4 / IP66, operating temperature is 0 to 50°C, and the 366 x 293 x 48.2 mm unit fits a 352 x 279 mm cutout or a 75 x 75 mm VESA mount. It is programmed only with the Simplified Chinese edition of EasyBuilder Pro.
