WECON PI3102i PI3000i Series 10.2-inch HMI Touch Panel
- Brand
- WECON
- Model
- PI3102i
- GEARWELL SKU
- GWP-000023890
- Category
- HMIs & Industrial PCs
Key specifications
- CPU
- Cortex-A7 528 MHz
- Power
- 24 V DC (12-28 V DC), <10 W
- Memory
- 128 MB RAM / 128 MB flash
- Display
- 10.2" TFT, 1024 x 600, 16,000k colours
- Brightness
- 350 cd/m2
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | WECON PI3102i PI3000i Series 10.2-inch HMI Touch Panel |
|---|---|
| Brand | WECON |
| Model | PI3102i |
| Category | HMIs & Industrial PCs |
| CPU | Cortex-A7 528 MHz |
| Power | 24 V DC (12-28 V DC), <10 W |
| Memory | 128 MB RAM / 128 MB flash |
| Display | 10.2" TFT, 1024 x 600, 16,000k colours |
| Brightness | 350 cd/m2 |
| Protection | IP65 (front panel) |
| Touch panel | Four-wire resistive |
| Communication | COM1 RS422/RS485 + RS232; 1 x Ethernet |
| Dimensions / cut-out | 272.0 x 190.0 x 41.5 mm / 260.0 x 179.0 mm |
