TURCK NI60-K90-AZ3X-B2131 K90 Rectangular Inductive Sensor
- Brand
- TURCK
- Model
- NI60-K90-AZ3X-B2131
- GEARWELL SKU
- GWP-000023226
- Category
- Proximity & Photoelectric Sensors
Key specifications
- Housing
- Rectangular K90, 103.7 x 75 x 60 mm, PBT-GF30-V0
- Ident no.
- 13542
- Output function
- 2-wire, NO contact
- Protection class
- IP67
- Operating voltage
- 20...250 VAC / 10...300 VDC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | TURCK NI60-K90-AZ3X-B2131 K90 Rectangular Inductive Sensor |
|---|---|
| Brand | TURCK |
| Model | NI60-K90-AZ3X-B2131 |
| Category | Proximity & Photoelectric Sensors |
| Housing | Rectangular K90, 103.7 x 75 x 60 mm, PBT-GF30-V0 |
| Ident no. | 13542 |
| Output function | 2-wire, NO contact |
| Protection class | IP67 |
| Operating voltage | 20...250 VAC / 10...300 VDC |
| Ambient temperature | -25...+70 °C |
| Mounting conditions | Non-flush |
| Electrical connection | Connector 7/8", 3-pin |
| Rated switching distance | 60 mm |
| Rated operational current | <= 400 mA AC / <= 300 mA DC |
