TURCK NI12U-EM18-AP4X-H1141 uprox M18 Inductive Proximity Sensor
- Brand
- TURCK
- Model
- NI12U-EM18-AP4X-H1141
- GEARWELL SKU
- GWP-000023225
- Category
- Proximity & Photoelectric Sensors
Key specifications
- Housing
- Threaded barrel M18 x 1, stainless steel 1.4301 (AISI 304)
- Code note
- NI12U-EM18-AP4X-H1141 is not listed in the current Turck online catalogue; housing/connection positions confirmed via NI12U-EM18-...-H1141 types
- Output code AP4X
- DC, PNP, normally open (as in Turck NI10U-EM18-AP4X-H1141/S367)
- Protection class
- IP68
- Special features
- Factor 1, resistant to magnetic fields, uprox+
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | TURCK NI12U-EM18-AP4X-H1141 uprox M18 Inductive Proximity Sensor |
|---|---|
| Brand | TURCK |
| Model | NI12U-EM18-AP4X-H1141 |
| Category | Proximity & Photoelectric Sensors |
| Housing | Threaded barrel M18 x 1, stainless steel 1.4301 (AISI 304) |
| Code note | NI12U-EM18-AP4X-H1141 is not listed in the current Turck online catalogue; housing/connection positions confirmed via NI12U-EM18-...-H1141 types |
| Output code AP4X | DC, PNP, normally open (as in Turck NI10U-EM18-AP4X-H1141/S367) |
| Protection class | IP68 |
| Special features | Factor 1, resistant to magnetic fields, uprox+ |
| Mounting conditions | Non-flush |
| Electrical connection | Connector M12 x 1 (H1141) |
| Rated switching distance | 12 mm |
