TENGEN JMB-500VA(Cu) 3-2/36 24 JMB Lighting Transformer
- Brand
- TENGEN
- Model
- JMB-500VA(Cu) 3-2/36 24
- GEARWELL SKU
- GWP-000021255
- Category
- Power Supplies
Key specifications
- Input voltage
- 380 / 220 V
- Rated capacity
- 500 VA
- Material number
- 05020060921
- Winding material
- Copper
- Code suffix "3-2/36 24"
- as collected; this exact tap set is not listed in the official SKU list (listed: JMB-500VA(铜) 3-2/36 24 12)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | TENGEN JMB-500VA(Cu) 3-2/36 24 JMB Lighting Transformer |
|---|---|
| Brand | TENGEN |
| Model | JMB-500VA(Cu) 3-2/36 24 |
| Category | Power Supplies |
| Input voltage | 380 / 220 V |
| Rated capacity | 500 VA |
| Material number | 05020060921 |
| Winding material | Copper |
| Code suffix "3-2/36 24" | as collected; this exact tap set is not listed in the official SKU list (listed: JMB-500VA(铜) 3-2/36 24 12) |
| Dimensions B x D x E (500 VA) | 205 x 235 x 185 mm |
| Output voltages (as collected) | 36 / 24 V |
