TENGEN DZ108-63 50[36-50] DZ108 Motor Protection Circuit Breaker

Key specifications

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	TENGEN DZ108-63 50[36-50] DZ108 Motor Protection Circuit Breaker
Brand	TENGEN
Model	DZ108-63 50[36-50]
Category	Circuit Protection
Frame	DZ108-63
Standards	GB/T 14048.2, GB/T 14048.4
Rated voltage	up to 660 V AC
Material number	01040010041
Rated frequency	50 Hz
Rated current In	50 A
Auxiliary contacts	none on body (1NO+1NC auxiliary contact can be added)
Trip current setting range	36-50 A
