Supmea LDG-SUP-A100-2CJCMCKAAM3N6WA0001 Electromagnetic Flowmeter
- Brand
- Supmea
- Model
- LDG-SUP-A100-2CJCMCKAAM3N6WA0001
- GEARWELL SKU
- GWP-000022312
- Category
- Pressure, Flow & Temperature
Key specifications
- Liner (N6)
- PTFE, -10 to 120 °C
- Accuracy (K)
- 0.5 %
- Brand note
- collected as 美控 meacon; brand Supmea (杭州美仪, publisher of the SUP- ordering codes); meacon's store sells the same series with MIK- codes
- Housing (WA)
- Compact, M20x1.5 gland, aluminium, IP65
- Maker note
- Meacon (Hangzhou Meikong); series and model key published on the Supmea official site
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Supmea LDG-SUP-A100-2CJCMCKAAM3N6WA0001 Electromagnetic Flowmeter |
|---|---|
| Brand | Supmea |
| Model | LDG-SUP-A100-2CJCMCKAAM3N6WA0001 |
| Category | Pressure, Flow & Temperature |
| Liner (N6) | PTFE, -10 to 120 °C |
| Accuracy (K) | 0.5 % |
| Brand note | collected as 美控 meacon; brand Supmea (杭州美仪, publisher of the SUP- ordering codes); meacon's store sells the same series with MIK- codes |
| Housing (WA) | Compact, M20x1.5 gland, aluminium, IP65 |
| Maker note | Meacon (Hangzhou Meikong); series and model key published on the Supmea official site |
| Code suffix "01" | as collected; not listed in the official model-number table |
| Nominal diameter | DN200 |
| Output and power (AA) | 4-20 mA + pulse + RS485, 220 VAC |
| Electrode material (M3) | 316L SS |
| Process connection (J, C) | JB/T 81 flange, PN16 |
| Remote cable length (00) | 0 m (compact only) |
| Body/flange material (MC) | Carbon steel |
