SMC AS3002F-10 AS-F In-line Speed Controller, One-touch Fittings
- Brand
- SMC
- Model
- AS3002F-10
- GEARWELL SKU
- GWP-000020847
- Category
- Fittings, Tubing & Vacuum
Key specifications
- Body size
- 300
- Proof pressure
- 1.5 MPa
- Controlled flow
- 920 L/min (ANR)
- Applicable tubing O.D.
- 10 mm
- Max. operating pressure
- 1 MPa
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | SMC AS3002F-10 AS-F In-line Speed Controller, One-touch Fittings |
|---|---|
| Brand | SMC |
| Model | AS3002F-10 |
| Category | Fittings, Tubing & Vacuum |
| Body size | 300 |
| Proof pressure | 1.5 MPa |
| Controlled flow | 920 L/min (ANR) |
| Applicable tubing O.D. | 10 mm |
| Max. operating pressure | 1 MPa |
| Min. operating pressure | 0.1 MPa |
| Ambient and fluid temperature | -5 to 60 (no freezing) °C |
