SMC AR30-02G-A AR-A Modular Pressure Regulator with Gauge
- Brand
- SMC
- Model
- AR30-02G-A
- GEARWELL SKU
- GWP-000020842
- Category
- Air Preparation
Key specifications
- Option
- Round type pressure gauge (G)
- Weight
- 0.34 kg
- Body size
- 30
- Construction
- Relieving type
- Set pressure range
- 0.05 to 0.7 MPa
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | SMC AR30-02G-A AR-A Modular Pressure Regulator with Gauge |
|---|---|
| Brand | SMC |
| Model | AR30-02G-A |
| Category | Air Preparation |
| Option | Round type pressure gauge (G) |
| Weight | 0.34 kg |
| Body size | 30 |
| Construction | Relieving type |
| Set pressure range | 0.05 to 0.7 MPa |
| Pipe thread / port size | Rc 1/4 (02) |
| Max. operating pressure | 1.0 MPa |
| Pressure gauge port size | 1/8 |
