SMC AC40C-06-B AC-B Filter + Mist Separator + Regulator Unit
- Brand
- SMC
- Model
- AC40C-06-B
- GEARWELL SKU
- GWP-000020833
- Category
- Air Preparation
Key specifications
- Weight
- 1.53 kg
- Body size
- 40 (3/4 port version)
- Components
- AF40-06-A + AFM40-06-A + AR40-06-B
- Set pressure range
- 0.05 to 0.85 MPa
- Pipe thread / port size
- Rc 3/4 (06)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | SMC AC40C-06-B AC-B Filter + Mist Separator + Regulator Unit |
|---|---|
| Brand | SMC |
| Model | AC40C-06-B |
| Category | Air Preparation |
| Weight | 1.53 kg |
| Body size | 40 (3/4 port version) |
| Components | AF40-06-A + AFM40-06-A + AR40-06-B |
| Set pressure range | 0.05 to 0.85 MPa |
| Pipe thread / port size | Rc 3/4 (06) |
| Max. operating pressure | 1.0 MPa |
| Mist separator rated flow | 1100 L/min (ANR) |
| Nominal filtration rating | AF: 5 µm, AFM: 0.3 µm |
