Siemens 6ES7222-1AD30-0XB0 S7-1200 SB 1222 5V High-Speed Output Board

Key specifications

Sinking/sourcing startup behavior: Sinking and sourcing loads have opposite active states. Default 0 V with no user program turns a sinking load ON.
Output current limits: 0.1 A maximum per output; 0.4 A maximum per common
Output voltage range: 5 V DC nominal; 4.25–6.0 V DC operating range
Power loss, typ.: 0.5 W
Pulse-train output frequency: 2 Hz–200 kHz

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	Siemens 6ES7222-1AD30-0XB0 S7-1200 SB 1222 5V High-Speed Output Board
Brand	Siemens
Model	6ES7222-1AD30-0XB0
Category	Industrial Automation Parts
Sinking/sourcing startup behavior	Sinking and sourcing loads have opposite active states. Default 0 V with no user program turns a sinking load ON.
Output current limits	0.1 A maximum per output; 0.4 A maximum per common
Output voltage range	5 V DC nominal; 4.25–6.0 V DC operating range
Power loss, typ.	0.5 W
Pulse-train output frequency	2 Hz–200 kHz
Dimensions — Depth	21 mm
Output protection	No short-circuit or overload protection
Product description	SIMATIC S7-1200, Digital output SB 1222, 4 DQ, 5V DC 200kHz
Weights — Weight, approx.	35 g
Product type designation	SB 1222, DQ 4x5 V DC 200 kHz
Number of digital outputs	4; MOSFET, solid-state (current-sinking/current-sourcing)
Operating temperature limits	-20…60 °C horizontal; -20…50 °C vertical
