Siemens 6BK1700-0BA20-0AA0 Communication Module
- Brand
- Siemens
- Model
- 6BK1700-0BA20-0AA0
- GEARWELL SKU
- GWP-000002785
- Category
- Industrial Automation Parts
Key specifications
- Dimensions — Depth
- 58.5 mm
- Product description
- LOGO! CMK2000 Communication module for integrating the LOGO! 8 "in the building system bus KNX;" connection 24 V DC 0.04A 1 RJ45 port for Ethernet 50 communication objects time-of-day synchronization Configuration/diagnostics via web interface
- Weights — Weight, approx.
- 0.14 kg
- IP degree of protection
- IP20
- Input current — Current consumption, max.
- 0.04 A
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Siemens 6BK1700-0BA20-0AA0 Communication Module |
|---|---|
| Brand | Siemens |
| Model | 6BK1700-0BA20-0AA0 |
| Category | Industrial Automation Parts |
| Dimensions — Depth | 58.5 mm |
| Product description | LOGO! CMK2000 Communication module for integrating the LOGO! 8 "in the building system bus KNX;" connection 24 V DC 0.04A 1 RJ45 port for Ethernet 50 communication objects time-of-day synchronization Configuration/diagnostics via web interface |
| Weights — Weight, approx. | 0.14 kg |
| IP degree of protection | IP20 |
| Input current — Current consumption, max. | 0.04 A |
| Ambient temperature during operation — max. | 55 °C |
| Design of electrical connection for supply voltage | 2 screw-type terminals: L+, M 0.5 mm² - 2.5 mm² Screw-type terminal: FE 0.5 mm² ... 6.0 mm² |
